Eagle horizontal windlass 12 V 1000 W with drum and 10 mm gypsy Quick

The Quick Eagle horizontal windlass makes raising the anchor and retrieving the anchor rode easier, without the need to handle the operation manually. Powered by a 12 V supply and equipped with a 1000 W electric motor, it is suitable for boats between 5 and 15 metres fitted with a compatible anchoring system.

Its compact design is particularly useful when deck space is limited, especially on smaller boats and RIBs.

This electric windlass features a combination gypsy designed to retrieve an anchor rode made up of both chain and rope. The integrated drum also allows you to handle suitable rope. The 10 mm gypsy must match the specifications of your chain and anchor rode.

The aluminium base incorporates the chain pipe, while the AISI 316 stainless steel drum is designed to withstand the demands of the marine environment. The sealed motor is equipped with a chain counter sensor, allowing you to monitor the length of chain paid out or retrieved when a compatible counting system is installed.

The Quick Eagle windlass is supplied with a control box and gypsy for integration into a suitable onboard electrical system.

Technical specifications of the Quick Eagle horizontal windlass, 12 V, 1000 W, with drum and 10 mm gypsy:

• Brand: Quick
• Range: Eagle
• Type: Horizontal electric windlass
• Voltage: 12 V
• Motor power: 1000 W
• Recommended boat length: 5–15 m
• Gypsy type: Combination gypsy for chain and rope
• Stated nominal diameter: 10 mm
• Drum: Yes, AISI 316 stainless steel
• Base: Aluminium with integrated chain pipe
• Motor: Sealed, with chain counter sensor
• Pulling force: 1,250 kg
• Lifting force: 130 kg
• Maximum lifting force: 390 kg
• Retrieval speed: 17.8 m/min
• Version: DC (direct current)
• Supplied components: Control box and gypsy
