SmartTune 1/4″ Cyclops Marine
1405,20 €
The SmartTune² 1/4″ sensor from Cyclops Marine measures real-time load on your rigging, giving you instant access to critical data directly on your smartphone or onboard displays via the Cyclops gateway. This cutting-edge innovation enhances both performance and safety on board.
On backorder
Compatible models :
The SmartTune 1/4″ sensor from Cyclops Marine is a true technological breakthrough for demanding sailors. Installed in place of a turnbuckle on your standing rigging, it accurately measures the tension on your shrouds and transmits the data directly to your smartphone.
By continuously monitoring the loads on your mast and rigging, it helps you fine-tune your sailboat’s trim. Whether you’re a racing enthusiast or a cruising sailor keen on preserving your rig over time, SmartTune is a compact, reliable, and easy-to-install tool that enhances safety and performance on board.
With a battery life of up to 2,000 hours and a full recharge in just one hour, the sensor is built to support extended sailing trips. Calibrated for a working load of 750 kg and with a breaking load of 1,550 kg, it’s ideal for small-diameter rigging applications.
Technical Specifications – SmartTune 1/4″ Cyclops Marine
-
Type: Load sensor for standing rigging
-
Data Transmission: Bluetooth to smartphone (dedicated app) or wireless integration with onboard electronics via Cyclops gateway
-
Calibrated Load: 750 kg
-
Breaking Load: 1,550 kg
-
Battery Life: Up to 2,000 hours
-
Recharge Time: 1 hour
-
Dimensions: 55 x 112 x 18 mm
-
Installation: Replaces standard turnbuckle
-
Use Case: Suitable for small-section rigging
| Weight | 0,18 kg |
|---|---|
| Dimensions | 5,5 × 11,2 × 1,8 cm |
