Smartlink² 5T ee Cyclops Marine

The Smartlink² 5T ee is a highly robust wireless load sensor, specifically designed for sailing applications where eye-to-eye (or pin-to-pin) connections are exposed to significant load. It integrates seamlessly into fixed rigging systems such as backstays, boom vangs, spinnaker poles or halyards on powerful yachts.

With a load capacity of up to 5,000 kg, the Smartlink² 5T ee offers an impressive ±1% accuracy, while remaining lightweight and highly durable thanks to its titanium body. It meets the stringent demands of offshore racing yachts and heavily loaded one-designs.

Data is transmitted in real-time via Bluetooth, either to the Cyclops app or to onboard displays (B&G, Garmin, NKE, Sailmon…) via the dedicated gateway. This live data feed enables precise tension adjustments according to wind and sea conditions, enhances repeatability of trim, and improves overall performance.

Rated IP68 waterproof, the sensor delivers up to 8,000 hours of battery life in low-energy mode and recharges wirelessly in just one hour. Its smart design and compact form make it easy to install on existing rigs without structural changes.

Technical specifications – Smartlink² 5 T ee

• Type: Wireless load sensor for rigid (eye-to-eye) connections

• Maximum load capacity: 5,000 kg

• Accuracy: ±1% of maximum load

• Dimensions: 122 mm × 62 mm × 24 mm

• Weight: Approx. 390 g

• Transmission: Bluetooth to Cyclops app or gateway

• Battery life: Up to 8,000 h (low-energy mode)

• Charging: Wireless inductive (1h full charge)

• Waterproofing: IP68 – long-term immersion

• Compatibility: Rigid eye-to-eye fixings (10–16 mm pin size)

• Recommended use: High-performance racing yachts, offshore rigs, high-load one-designs

• Related category: Electronics
